UNIWELD R1563 Nitrogen Cylinder Regulator
R1563 UNIWELD® Nitrogen Cylinder Style Regulator
- Light to Medium Duty
- Body is machined from class "A" brass
- Chrome plated housing cap
- Internal pressure relief valve
- Sintered bronze inlet filter
- Stem-type seat assembly for more reliable seating
- 2" gauges for easy reading
- 1-1/4" diaphragm
- Weight: 2 lbs .75 oz
- UL listed
- MAX inlet pressure 3000 PSI
- MAX delivery pressure 5 - 175 PSI
- Inlet Gauge 2", 4000 PSI
- Outlet Gauge 2", 300 PSI
- Inlet Connection / Regulator Nut = CGA580
- Outlet Connection 1/4" SAE FLARE
